KV-45X
KV-45X
Detail
Length : 385 mm
Weight : 5.4 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 175 cc
■ Function :
KV-45X can be applied with different functional adapters as cable cutter, sleeve & lug crimper and compatibility heads.
Max pressure : 700 bar
Max output : 14.01 tons / 124.6 kN
Ram stroke : 45 mm
※ 5 adapter heads are sold separately.
| KV-45X with CP-27 (Crimping Head Adapter) |
KV-45X with SC-45 (Cable Cutter Head Adapter) |
|---|---|
| Main application: up to 400 mm² CU Die Sold Separately: (CU-16/25/35/50/70/95/120/150/185/240/300/400) ※ Accept all 12 tons die sets. ■ Hex Dies for Copper Lugs Accepts all dies used by Alcoa, Burndy, T&B, Klauke, Cembre and Blackburn 12 ton U-type and hex-type dies. Suitable for terminals with the standard of DIN46235. |
Cutting Capacity: ACSR: 40 mm Copper: 45 mm |
| KV-45X with DL-400MX (Die-less Hex Crimping Head Adapter) |
KV-45X with 65YC (Cable Cutter Head Adapter) |
| Crimping Capacity: 10 ~ 400 mm² Crimping Width: 10 mm Suitable Material: Multi-Core XLPE, XLPE, Terminals and Tubs for CU and AL cables, Coaxial Cable Suitable for terminals with the standard of DIN46235 |
Cutting Capacity: Cu Strands: 60 mm Al Strands: 60 mm CCP Cable: 65 mm Underground Cable: 65 mm (Except Armoured Cable) |
| KV-45X with SW150 (Spreader Adapter) | |
| Spreading Range: 5 mm ~ 150 mm Spreading Force: 6 Ton |
|
