Detail
Length : 344 mm
Weight : 3.8 kgs(w/o battery)
■ Specifications:
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Reservoir capacity : 48 cc
■ Cutting capacity :
Max pressure : 700 bar
Oil required : 25 cc
Max output : 7.45 tons / 66.3 kN
Wire rope 6x7 : 24 mm
Wire rope 6x12 : 24 mm
Wire rope 6x19 : 24 mm
Soft copper bar : 23 mm
Soft aluminum bar : 24 mm
Soft steel bar : 16 mm
Cu strands : 24 mm
Al strands : 24 mm
ACSR : 24 mm
※Cutting of piano wire is prohibited.
